RTS Game Tutorial | Unity | Episode 1 - Basic Unit Movement

Main summary

Key takeaways

Technology

Video goal / what’s being built

  • Tutorial series for an RTS (Real-Time Strategy) game in Unity: aims to cover typical RTS elements such as unit control, combat, base building, and resource management.
  • This episode specifically focuses on basic unit movement (click-to-move) using NavMesh.

Project setup (Unity + templates)

  • Uses Unity 2002 LTS (recommended by the author for the tutorial).
  • Creation steps:
    • Install the exact Editor version via Unity Hub (pre-releases/install editor list).
    • Use the 3D URP template.
    • Create an organized folder structure (an assets folder plus a new subfolder named m to store unnecessary items more cleanly).

Terrain creation and camera positioning (RTS-style view)

  • Creates a simple 3D Terrain so there is a ground surface for raycasting and navigation.
  • Builds an RTS-style camera concept:
    • Top-down but angled (rotation on the X-axis set to 45°).
    • Notes that camera movement will be scripted in a later episode, so no camera scripts are added yet.

Unit creation + navigation setup

  • Creates a basic unit:
    • A 3D Capsule (resized/corrected position so it sits on the terrain).
    • Adjusts CapsuleCollider radius (set to 0.3).
  • Adds a NavMesh Agent so the unit can pathfind:
    • Requires installing AI Navigation via Window → Package Manager.
    • Notes current settings are left mostly default, with intent to fine-tune later (including obstacle avoidance radius adjustment).

Click-to-move implementation (raycast + NavMesh destination)

  • Adds a script: unit movement to the capsule.
  • Script behavior (conceptually):
    • References the Main Camera.
    • References the unit’s NavMeshAgent.
    • Uses a Raycast from the camera through the mouse position when the right mouse button is clicked.
    • Uses a LayerMask so the raycast only registers hits on the Ground layer.
    • If the raycast hits the ground, the unit calls:
      • agent.SetDestination(hitPosition)
  • Layer setup:
    • Creates a new layer named ground.
    • Assigns the Terrain to that ground layer so clicks register on walkable surfaces.

Making the terrain walkable (NavMesh baking differences in Unity 2002)

  • Explains an issue: simply adding NavMesh previously might have worked, but in Unity 2002 some older workflows are obsolete.
  • Fix uses the newer approach:
    • Select Terrain
    • Add a NavMesh Surface component (non-obsolete workflow).
    • Enable Bake, then wait a moment.
    • Uses Gizmos to verify baking:
      • Walkable areas turn blue after baking.
  • After baking, clicking on the terrain successfully moves the unit via NavMesh.

Camera adjustment for playtesting

  • Adjusts camera position closer so the unit is visible (angle left as-is).

Demonstration + plan for next episode (selection logic)

  • Demonstrates that every unit with the movement script moves, since clicking sends all agents to the same destination.
  • Plans the next episode to implement unit selection so only the selected unit(s) move when clicking.

Main speakers / sources

  • Speaker: The tutorial creator (single host) guiding through Unity steps and code setup.
  • Source: Unity (Unity Hub / Package Manager / NavMesh Agent / NavMesh Surface, Raycasting, LayerMask).
