Adjust Until Barely Visible" is a Lie. (Fix Washed Out Games) (PS5, Xbox, PC)

Summary of Technological Concepts / Fixes for “Washed Out” Game Brightness (PS5, Xbox, PC)

Root cause: brightness/black-level standards changed with digital video

• With CRT displays, there was a more consistent expectation:
  • Black = 16
  • White = 235
  • (Optionally, some setups allowed “super white” above 235.)
• With modern consoles using digital 0–255 signals (HDMI era), the standard became inconsistent.
• Developers added toggles like Full RGB vs Limited, but this can cause:
  • Different games to use different black levels
  • Resulting visuals that look washed out or otherwise incorrect.

Why game-by-game settings don’t work reliably

• Example: Half-Life 2 on PC
  • The game is said to want a black level of 8
  • Which matches neither:
    • TV black (16)
    • PC black (0)
• This creates a “wild west” where developers place black differently, so game brightness patterns often can’t be trusted.

Recommended RGB/Range strategy (with important hardware caveats)

• The general “intended” approach:
  • PC → Full range
  • TV → Limited range
• Many modern TVs can do both, but the speaker recommends:
  • Using Full range on TV for consistent handling across inputs.
• PlayStation (PS5) issue
  • The speaker claims PS5 always outputs 0–255 even when set to limited.
  • This may prevent truly running “limited” correctly.
• Xbox (issue mentioned)
  • Using Xbox’s calibration tool in PC RGB hides a visibility element.
  • Switching to limited can make brightness adjustment require extreme changes, which is difficult because games vary.

The proposed practical fix: target a new “black cutoff”

• Instead of aiming for:
  • TV black = 16, or
  • PC black = 0
• The video proposes using a target black level of 4.
• Claim: Level 4 corresponds to about ~1.5% brightness, aligning with the “Zone 2” concept from photography (Ansel Adams).
  • In Zone 2, black becomes just barely visible as texture.
• Goal of calibration:
  • Ensure the darkest game details are barely visible
  • Avoid crushing blacks into pure black
  • Avoid making shadows turn into flat gray

Second problem: gamma — don’t change it

• The speaker warns that ~90% of games get gamma wrong and that gamma is not a simple brightness control.
• If a game offers a gamma slider, leave it alone, because sliders can:
  • Lift blacks (destroy depth), or
  • Over-darken / alter colors (depending on direction)
• Instead, use display calibration.

Calibration patterns / what to check

• Bar “4”
  • Target “zone two”
  • Everything below should be pure black
  • 4 should be barely visible
• White level
  • Aim to see about 253
  • If you can’t see it, or if bars turn pink/red, the speaker says contrast is too high
• Color temperature
  • Typically Warm/Normal is most accurate, but it varies by TV model
  • Recommendation: look up recommended settings by TV make/model

Additional notes

• The speaker argues developers have been getting this wrong since the PS3 era, and suggests it’s unlikely to be fixed soon.
• Mentions a Discord link (in the description) to download the calibration images/patterns.

---
