[온라인수업 고급화학] 6번째 원자가결합 이론과 혼성오비탈

Main ideas / lessons

1) From Lewis structures to orbital-based bonding theories

• Lewis structures model shared electrons as electron pairs drawn as dots/lines positioned between two atoms.
• Limitation: Lewis structures cannot specify the exact electron positions.
• Quantum mechanics motivation:
  • By the uncertainty principle, an electron’s exact location cannot be determined.
  • Electrons exhibit wave-particle duality, so their presence is described by a probability distribution—an orbital concept.
• Modeling shift:
  • Instead of bonding electrons as a fixed pair of points, bonding is described through orbital overlap and probability density.

2) Valence bond concept (“original bonding theory”)

In this perspective, bonding is described by:

• Overlapping atomic orbitals from two bonding atoms.
• Forming a new combined wavefunction that increases the probability of finding electrons between the nuclei.

Key interpretation vs. Lewis:

• Lewis drawings: “Place an electron pair here.”
• Orbital theory: “The probability density between nuclei increases, so electrons are very likely to be shared there.”

Terminology note:

• The model is presented as an expansion beyond Lewis bonding using orbitals (referred to as the speaker’s reference to an “original author’s bonding theory,” i.e., a valence bond / orbital-overlap viewpoint).

3) Types of covalent bonds in valence bond theory: σ and π

Two bond types are distinguished:

• σ (sigma) bond
• π (pi) bond

“Original electrons” meaning (as explained):

• The speaker’s interpretation is that bonding electrons refer to those in the outermost shell, based on energy/order arguments.

Orbital directionality matters:

• s orbitals: non-directional (spherical), so orientation doesn’t control bonding.
• p orbitals: directional (dumbbell-shaped), with three possible orientations (along axes such as x, y, z).

σ bond formation

• Occurs when orbital overlap is head-on, including the internuclear axis (between nuclei).
• Probability density indicates electron presence between atoms without a nodal plane through the internuclear axis.

π bond formation

• Occurs when two p orbitals overlap side-by-side (parallel).
• Characteristic feature: a nodal plane where electron probability is zero in certain regions (including behavior that does not place the density along the internuclear axis in that plane).

4) Hybridization: creating equivalent orbitals that match observed geometry

Purpose of hybridization:

• Pure Lewis/valence-bond orbital assignments can imply energy mismatches for bonding electrons.
• Hybridization provides a set of equivalent orbitals that produce the correct shapes and bond angles.

Mechanism described:

• Mix one s orbital with a number of p orbitals to form new hybrid orbitals with intermediate, equivalent energy.

Core “instruction-style” rule:

• Hybridization type is determined by the number of electron-pair “directions” (electron domains) around the central atom.

sp³ hybridization (example: methane CH₄; tetrahedral electron geometry)

• Given: Carbon needs four bonding directions → use one s + three p.
• Result: Four sp³ orbitals, arranged tetrahedrally.
• Geometry: tetrahedral electron geometry corresponds to a bond angle of about 109.5°.
• Bonding with hydrogen:
  • Each H 1s orbital overlaps head-on with an sp³ orbital → σ bonds.
• Examples emphasizing lone pairs:
  • NH₃ (ammonia) and H₂O (water) show that:
    • bonding + nonbonding pairs occupy tetrahedral electron-domain positions,
    • but molecular shape uses only bonding positions (lone pairs are excluded from the molecular geometry).

5) Distinguish “electron geometry” vs “molecular geometry”

• Electron (electromagnetic) structure / electron-domain shape

  • Based on arrangement of all electron pairs (bonding + nonbonding).
  • Often uses a tetrahedral template.

• Molecular geometry

  • Based only on positions of atoms connected by covalent bonds.
  • Lone pair positions are ignored when naming the molecular shape.

Explained trends:

• CH₄ → tetrahedral
• NH₃ → trigonal pyramidal
• H₂O → bent

6) sp² and sp hybridization (geometry and remaining p orbitals)

sp² hybridization

• One s + two p → three sp² orbitals arranged trigonal planar.
• One p orbital remains unhybridized and sits perpendicular to the plane.
• That remaining p orbital enables π bonding.

sp hybridization

• One s + one p → two sp orbitals arranged linear (180°).
• Two p orbitals remain perpendicular to each other and can contribute to π bonding.

7) Applying hybridization to multiple bonds (ethylene C₂H₄, acetylene C₂H₂)

General approach

1. Use a Lewis structure to identify bond patterns (double/triple).
2. Apply hybridization to carbon atoms:
   • C=C: one σ + one π
   • C≡C: one σ + two π

Ethylene (C₂H₄)

• Each carbon has three electron-pair directions → sp² on each carbon.
• C–C bonding:
  • sp² orbitals overlap head-on → σ
  • remaining parallel p orbitals overlap side-by-side → π
• C–H bonds: each is a σ bond from overlap with sp² orbitals.

Acetylene (C₂H₂)

• Each carbon has two electron-pair directions → sp hybridization.
• C–C bonding:
  • sp–sp overlap head-on → σ
  • two p orbitals form two π bonds.

8) Bond strength and reactivity: σ vs π implications

• The key takeaway for reactivity:
  • π bonds are more weakly held / easier to break than σ bonds.
• Therefore:
  • Single bonds are harder to break.
  • Double/triple bonds react more readily because π bonds break first, enabling addition reactions.
  • Triple bonds break π bonds sequentially.

9) Lesson wrap-up and preview

• Today’s update:
  • Valence bond / hybrid orbital approach, extending Lewis structures with orbital probability and overlap.
• Next preview:
  • Molecular orbital theory, focusing on energy levels when molecules form.

---

Method / instruction-like bullet points (as presented)

A) How to model bonding beyond Lewis structures (orbital-overlap idea)

• Replace “electron pair as dots between atoms” with:
  • Identify which atomic orbitals participate.
  • Describe bonding as:
    • orbital overlap bringing electron probability from each atom together,
    • increased probability density of finding electrons between nuclei.
• Quantum motivation:
  • Electron positions are uncertain → use probability distributions (orbitals).

B) How to decide σ vs π bonding during overlap

• Determine bond type by overlap geometry:
  • σ bond:
    • orbitals overlap head-on
    • overlap includes the internuclear axis
  • π bond:
    • orbitals overlap side-by-side
    • typically involves parallel p orbitals
    • includes nodal-plane behavior (zero electron density in certain planes)

C) How to determine hybridization (sp³ / sp² / sp)

• Count the number of electron-pair directions (electron domains) around the central atom.
• Then hybridize:
  • 4 directions → sp³
    • 1 s + 3 p → 4 hybrid orbitals
    • tetrahedral electron geometry
  • 3 directions → sp²
    • 1 s + 2 p → 3 hybrid orbitals
    • trigonal planar electron geometry
    • one remaining p orbital enables π bonding
  • 2 directions → sp
    • 1 s + 1 p → 2 hybrid orbitals
    • linear electron geometry
    • remaining p orbitals enable π bonding

D) How to get molecular geometry vs electron geometry

1. Build the electron-domain shape using bonding + lone pairs.
2. Convert to molecular geometry:
   • remove lone-pair positions,
   • keep only bonded-atom positions.

Then predict shapes such as:

• tetrahedral (CH₄),
• trigonal pyramidal (NH₃),
• bent (H₂O),
• trigonal planar/linear cases for sp²/sp.

E) How to interpret multiple bonds using hybrid orbitals

• C=C double bond
  • σ: head-on overlap of hybrid orbitals
  • π: side-by-side overlap of remaining unhybridized p orbitals
• C≡C triple bond
  • 1 σ: head-on overlap of hybrid orbitals
  • 2 π: two side-by-side overlaps of remaining p orbitals

F) Predict relative ease of breaking bonds for reactivity

• π bonds break more easily than σ bonds.
• Therefore, double/triple bonds undergo addition reactions more readily because π interactions can be disrupted first.

---

Speakers / sources featured

• Teacher Choi Yeo-ul (main speaker)
• Course/textbook diagrams are referenced (textbook not explicitly named; no other specific source identified)
